SELECT YOUR STYLE

Select Body

Select Drive

Select Grade

CX 5 KN6ALAA 46V KD6 EXT 360 36 PNG 0018

GT

  • 17" Alloy Wheels
  • Leather Trim
  • Climate Control
  • Car Play
CX 5 KN6ALAA 46V KD6 EXT 360 36 PNG 0018

Signature

  • 19" Alloy Wheels
  • Signature Illumination
  • Bose Surround

Mazda CX-5 Features

  • SAFETY

    Advanced front air bags with seat belt-use, passenger-weight sensors
    Front side-impact air bags and side-impact air curtains with rollover protection
    3-point seat belts for all seating positions
    Front seat belt pretensioners with force limiters
    Anti-lock Brake System with Electronic Brake Force Distribution
    Dynamic Stability Control and Traction Control System
    Hill Launch Assist
    Side-impact door beams
    LATCH rear seat child safety seat anchors & upper tether anchors
    Child safety rear door locks

  • ENGINE

    2.5L
    Engine type SKYACTIV®-G 2.5L DOHC 16-valve 4-cylinder with Cylinder Deactivation
    Maximum power 139.4 kW @ 6,000 rpm / Horsepower 187 hp @ 6,000 rpm
    Torque 252.1 Nm @ 4,000 rpm / Torque 186 lb-ft @ 4,000 rpm
    Redline 6,500 rpm
    Displacement (cc) 2488
    Bore x stroke (mm) 89 x 100
    Compression ratio 13.0 : 1
    Fuel system Advanced Direct Injection
    Recommended fuel Regular unleaded
    Valvetrain Chain-driven dual overhead cams, 4-valves per cylinder with variable valve timing (VVT)
    Ignition system Direct coil-on-plug electronic ignition with platinum-tipped spark plugs
    Engine block Aluminum alloy
    Cylinder head Aluminum alloy
    SKYACTIV-VEHICLE DYNAMICS with G-Vectoring Control

    DRIVETRAIN

    I-ACTIV AWD®
    Automatic transmission SKYACTIV®-Drive 6-Speed automatic transmission with manual-shift and Sport mode

    GEAR RATIOS (:1) Automatic Transmission
    1st 3.552
    2nd 2.022
    rd 1.452
    4th 1.000
    5th 0.708
    6th 0.599
    Reverse 3.893
    Final drive 4.325 (FWD) / 4.624 (AWD)

    CHASSIS

    Brakes 4-wheel disc, diagonal hydraulic
    - Front 297-mm vented disc
    - Rear 302-mm solid disc
    - ABS 4-wheel, 4-channel with Electronic Brake Force Distribution (EBD)
    Steering type Power rack-and-pinion with variable assist
    Power assist Electronic Power Assist Steering (EPAS)
    Overall steering ratio 15.5:1
    Steering wheel turns, lock-to-lock 2.7
    Turning circle diameter, curb-to-curb (m) 10.9
    Suspension 4-wheel independent
    - Front MacPherson strut with stabilizer bar
    - Rear Multilink with stabilizer bar

    WEIGHTS & CAPACITIES

    Curb weight (kg) 1,675.1 (AWD)
    Towing Capacity (kg) 907.1
    Fuel capacity (liters) 57.9 (AWD)

  • COMFORT & CONVENIENCE

    Dual-zone automatic climate control with pollen filter
    Rear air conditioning vents
    Power sliding-glass moonroof with one-touch-open feature and interior sunshade
    Power windows with driver's one-touch down/up feature
    Speed sensitive power door locks with 2-stage unlocking
    Mazda Advanced Keyless Entry and Start System
    Auto-dimming rearview mirror
    Push Button Start Electronic parking brake
    Dual covered illuminated visor vanity mirrors
    Tilt & telescopic steering column
    Map lights, Dome light and Cargo area light
    Remote fuel-door release
    Rear window defogger with timer

    STORAGE

    Overhead console with sunglasses holder
    Center console armrest with tray and covered storage bin
    Rear seat center armrest with integrated cup holders
    Front and rear door bottle holders/storage
    Driver and Front passenger seatback pockets

    SEATING & TRIM

    5-passenger seating capacity
    8-way power driver's seat with power lumbar support
    Adjustable front and rear headrests
    Leather-trimmed seats
    Leather-wrapped steering wheel
    Leather-wrapped gear selector
    Carpet floor mats

    AUDIO & INFOTAINMENT

    7" full-color touch screen display
    8 Full Range Speakers
    Bluetooth® hands-free phone and audio capability HD Radio™
    Apple carplay / android auto

    Mazda Navigation System
    Rearview Camera

    MAZDA CONNECT™ Infotainment System
    - Infotainment system voice command
    - Multifunction Commander Control
    - Aha™ internet radio integration
    - Stitcher™ internet radio integration
    - SMS text message audio delivery and reply

    Auxiliary audio input jack
    USB Inputs, 2 front and 2 rear
    Steering wheel-mounted audio, phone and cruise controls

    INSTRUMENTATION

    Speedometer, tachometer and fuel gauge, black background with white lettering and silver surround
    Ambient temperature & clock display
    Multi-Information Display (MID) with Trip computer

  • BODY

    LED Headlights
    LED fog lights
    Auto on/off headlights
    Rain-sensing variable-intermittent windshield wipers I
    ntermittent rear wiper/washer
    Body-colored power side mirrors with integrated turn signals
    Rear privacy glass
    Roof-mounted "shark fin" antenna
    Body-colored rear roof spoiler
    Dual exhaust outlets with bright finish

    WHEELS & TIRES

    Wheel size (cm) 49.2 x 19.2 aluminum alloy
    Wheel size and type P225/65 R17 all-season tires
    Temporary spare tire T145/90D16

    EXTERIOR DIMENSIONS

    Wheelbase (mm) 2,697
    Track, front (mm) 1,595
    Track, rear (mm) 1,521
    Length (mm) 4,549
    Width (mm) 1,842
    Height (mm) up to roof, without roof rails, FWD/AWD 1,661 / 1,659
    Height (mm) up to roof, without roof rails, up to sharkfin antenna
    AWD 1,679
    Minimum ground clearance - Unladen (mm) 190.5

Mazda CX-5 Features

  • SAFETY

    Advanced front air bags with seat belt-use, passenger-weight sensors
    Front side-impact air bags and side-impact air curtains with rollover protection
    3-point seat belts for all seating positions
    Front seat belt pretensioners with force limiters
    Anti-lock Brake System with Electronic Brake Force Distribution
    Dynamic Stability Control and Traction Control System
    Hill Launch Assist
    Side-impact door beams
    LATCH rear seat child safety seat anchors & upper tether anchors
    Child safety rear door locks

  • ENGINE

    2.5L
    Engine type SKYACTIV®-G 2.5L DOHC 16-valve 4-cylinder with Cylinder Deactivation
    Maximum power 139.4 kW @ 6,000 rpm / Horsepower 187 hp @ 6,000 rpm
    Torque 252.1 Nm @ 4,000 rpm / Torque 186 lb-ft @ 4,000 rpm
    Redline 6,500 rpm
    Displacement (cc) 2488
    Bore x stroke (mm) 89 x 100
    Compression ratio 13.0 : 1
    Fuel system Advanced Direct Injection
    Recommended fuel Regular unleaded
    Valvetrain Chain-driven dual overhead cams, 4-valves per cylinder with variable valve timing (VVT)
    Ignition system Direct coil-on-plug electronic ignition with platinum-tipped spark plugs
    Engine block Aluminum alloy
    Cylinder head Aluminum alloy
    SKYACTIV-VEHICLE DYNAMICS with G-Vectoring Control

    DRIVETRAIN

    I-ACTIV AWD®
    Automatic transmission SKYACTIV®-Drive 6-Speed automatic transmission with manual-shift and Sport mode

    GEAR RATIOS (:1) Automatic Transmission
    1st 3.552
    2nd 2.022
    rd 1.452
    4th 1.000
    5th 0.708
    6th 0.599
    Reverse 3.893
    Final drive 4.325 (FWD) / 4.624 (AWD)

    CHASSIS

    Brakes 4-wheel disc, diagonal hydraulic
    - Front 297-mm vented disc
    - Rear 302-mm solid disc
    - ABS 4-wheel, 4-channel with Electronic Brake Force Distribution (EBD)
    Steering type Power rack-and-pinion with variable assist
    Power assist Electronic Power Assist Steering (EPAS)
    Overall steering ratio 15.5:1
    Steering wheel turns, lock-to-lock 2.7
    Turning circle diameter, curb-to-curb (m) 10.9
    Suspension 4-wheel independent
    - Front MacPherson strut with stabilizer bar
    - Rear Multilink with stabilizer bar

    WEIGHTS & CAPACITIES

    Curb weight (kg) 1,675.1 (AWD)
    Towing Capacity (kg) 907.1
    Fuel capacity (liters) 57.9 (AWD)

  • COMFORT & CONVENIENCE

    Dual-zone automatic climate control with pollen filter
    Rear air conditioning vents
    Power sliding-glass moonroof with one-touch-open feature and interior sunshade
    Power windows with driver's one-touch down/up feature
    Speed sensitive power door locks with 2-stage unlocking
    Mazda Advanced Keyless Entry and Start System
    Auto-dimming rearview mirror
    Push Button Start Electronic parking brake
    Dual covered illuminated visor vanity mirrors
    Tilt & telescopic steering column
    Map lights, Dome light and Cargo area light
    Remote fuel-door release
    Rear window defogger with timer

    STORAGE

    Overhead console with sunglasses holder
    Center console armrest with tray and covered storage bin
    Rear seat center armrest with integrated cup holders
    Front and rear door bottle holders/storage
    Driver and Front passenger seatback pockets

    SEATING & TRIM

    5-passenger seating capacity
    8-way power driver's seat with power lumbar support
    Adjustable front and rear headrests
    Leather-trimmed seats
    Leather-wrapped steering wheel
    Leather-wrapped gear selector
    Carpet floor mats

    AUDIO & INFOTAINMENT

    7" full-color touch screen display
    Bose® 10-speaker audio system with Centerpoint® 2 and AudioPilot® 2
    Bluetooth® hands-free phone and audio capability HD Radio™
    Apple carplay / android auto

    Mazda Navigation System
    Rearview Camera

    MAZDA CONNECT™ Infotainment System
    - Infotainment system voice command
    - Multifunction Commander Control
    - Aha™ internet radio integration
    - Stitcher™ internet radio integration
    - SMS text message audio delivery and reply

    Auxiliary audio input jack
    USB Inputs, 2 front and 2 rear
    Steering wheel-mounted audio, phone and cruise controls

    INSTRUMENTATION

    Speedometer, tachometer and fuel gauge, black background with white lettering and silver surround
    Ambient temperature & clock display
    Multi-Information Display (MID) with Trip computer

  • BODY

    LED Headlights
    LED Daytime Running Lights
    LED fog lights
    LED Combination taillights
    Auto on/off headlights
    Rain-sensing variable-intermittent windshield wipers I
    Intermittent rear wiper/washer
    Body-colored power side mirrors with integrated turn signals
    Rear privacy glass
    Roof-mounted "shark fin" antenna
    Body-colored rear roof spoiler
    Dual exhaust outlets with bright finish

    WHEELS & TIRES

    Wheel size (cm) 48.26 x 17.78 aluminum alloy
    Wheel size and type P225/55 R19 all-season tires
    Temporary spare tire T145/90D16

    EXTERIOR DIMENSIONS

    Wheelbase (mm) 2,697
    Track, front (mm) 1,595
    Track, rear (mm) 1,521
    Length (mm) 4,549
    Width (mm) 1,842
    Height (mm) up to roof, without roof rails, FWD/AWD 1,661 / 1,659
    Height (mm) up to roof, without roof rails, up to sharkfin antenna
    AWD 1,679
    Minimum ground clearance - Unladen (mm) 190.5
